Mahsulotlar tavsifi
Pastki LID
Yuqori anti-PID ishlashi
Quyi hujayradan modulga (CTM) yo'qotish darajasi, yuqori samarali modul uchun ko'proq mos keladi
Nisbiy konversiya samaradorligi past yorug'likda (200W/m²) 92% dan yuqori yoki unga teng
Old samaradorlik 25% dan katta yoki unga teng , Ikki yuzli tezlik 80% dan katta yoki teng
Texnik ma'lumotlar
| Element | Spetsifikatsiya |
|---|---|
| Model | 210-16 BB monokristalli ikki yuzli quyosh batareyasi |
| Hajmi | 182,3 mm × 105 mm ± 0,5 mm, diagonal (chiziq) 207,35 mm ± 0,5 mm |
| Qalinligi | 130μm ±13 μm |
| Old | 16 shina, 7 yostiq, 118 barmoq, shina kengligi 0,06 mm ± 0,03 mm |
| Orqaga | 16 avtobus, 7 yostiq, 114 barmoq, shina kengligi 0,06 mm ± 0,03 mm |
| Element | Qiymat |
|---|---|
| Joriy (Isc) | +0.045%/K |
| Voltaj (Voc) | -0.250%/K |
| Quvvat (Pmax) | -0.300%/K |
| Eff (%) | Pmp (Vt) | Vmp (V) | Import (A) | Ovoz (V) | Isc (A) | FF (%) |
|---|---|---|---|---|---|---|
| 26.3 | 5.02 | 0.646 | 7.774 | 0.742 | 7.868 | 85.95 |
| 26.2 | 5.00 | 0.645 | 7.751 | 0.741 | 7.867 | 85.84 |
| 26.1 | 4.98 | 0.645 | 7.731 | 0.739 | 7.865 | 85.74 |
| 26.0 | 4.96 | 0.643 | 7.716 | 0.738 | 7.863 | 85.55 |
| 25.9 | 4.94 | 0.642 | 7.701 | 0.737 | 7.861 | 85.37 |
| 25.8 | 4.93 | 0.641 | 7.688 | 0.736 | 7.859 | 85.19 |
| 25.7 | 4.91 | 0.639 | 7.678 | 0.735 | 7.858 | 84.99 |
| 25.6 | 4.89 | 0.638 | 7.659 | 0.734 | 7.856 | 84.81 |
| 25.5 | 4.87 | 0.636 | 7.652 | 0.732 | 7.855 | 84.61 |
| 25.4 | 4.85 | 0.635 | 7.636 | 0.731 | 7.854 | 84.41 |
| 25.3 | 4.83 | 0.634 | 7.616 | 0.730 | 7.852 | 84.24 |
| 25.2 | 4.81 | 0.633 | 7.599 | 0.730 | 7.848 | 84.01 |
| 25.1 | 4.79 | 0.633 | 7.575 | 0.729 | 7.846 | 83.82 |
| 25.0 | 4.77 | 0.631 | 7.563 | 0.727 | 7.845 | 83.68 |
| 24.9 | 4.75 | 0.629 | 7.552 | 0.726 | 7.837 | 83.56 |
| 24.8 | 4.73 | 0.628 | 7.535 | 0.725 | 7.836 | 83.36 |
| 24.7 | 4.72 | 0.627 | 7.519 | 0.724 | 7.836 | 83.15 |
| 24.6 | 4.70 | 0.626 | 7.506 | 0.723 | 7.834 | 82.97 |
| 24.5 | 4.68 | 0.624 | 7.495 | 0.722 | 7.833 | 82.76 |
| 24.4 | 4.66 | 0.623 | 7.477 | 0.720 | 7.828 | 82.60 |
| 24.3 | 4.64 | 0.621 | 7.470 | 0.719 | 7.826 | 82.41 |
| 24.2 | 4.62 | 0.619 | 7.465 | 0.719 | 7.824 | 82.19 |
| 24.1 | 4.60 | 0.617 | 7.459 | 0.717 | 7.821 | 82.01 |
